Lithium-Ion Battery Fires & BESS
Thermal Runaway, NFPA 855, and Why Water Alone Won't Work

Lithium-ion is the fastest-growing fire-protection challenge in the United States. Cell phones, e-bikes, EVs, and grid-scale battery energy storage systems (BESS) all share one failure mode: thermal runaway. The fires are intense, self-oxidizing, and unlike anything in the fire-protection canon. Here's what NFPA 855 actually requires, what UL 9540A tells you, and what an inspector should look for.

By Stanislav Samek, Samektra · 13 min read · Reviewed May 2026

Why this is the fastest-growing fire-protection topic

Lithium-ion is everywhere. Every phone, laptop, e-bike, e-scooter, electric vehicle, power tool, residential energy-storage system (Tesla Powerwall, LG Chem RESU, etc.), and every utility-scale battery energy-storage system (BESS) deployed since about 2010 uses some flavor of lithium-ion chemistry. The technology is brilliant — high energy density, long cycle life, no memory effect — but it has a single, well-known failure mode that the fire-protection community has been catching up to for the last decade.

That failure mode is thermal runaway. Once a cell crosses about 150°C, the separator between anode and cathode melts and the cell shorts internally. The electrolyte (a flammable organic carbonate solvent like ethylene carbonate or dimethyl carbonate) vaporizes, ignites, and the cathode releases its bound oxygen. The cell now has fuel, oxidizer, and a heat source all in the same package — and it transfers that heat to neighboring cells fast enough to cascade through an entire battery pack in seconds to minutes.

The Surprise, AZ BESS explosion (April 2019) hospitalized 9 firefighters when accumulated battery off-gas (hydrogen + carbon monoxide + electrolyte vapor) deflagrated as they opened the container door. Moss Landing, CA (multiple fires 2021-2024) burned for days each time. Tesla Megapack at Otay Mesa, CA burned for 5 days in 2024. Every one of these involved a fully NFPA-855-compliant install. The standard works — but only if everything is built and inspected to the spec, and if responders treat these incidents differently from any other fire.

Where the rules live

The fire-protection rulebook for lithium-ion is layered:

NFPA 855 — Stationary ESS (the umbrella)

The 2023 edition is the current reference for fire-marshal review of any installed energy-storage system over 1 kWh. It mandates UL 9540 listing, UL 9540A propagation testing, spacing matrices, ventilation, gas detection, suppression, and a Hazard Mitigation Analysis (HMA) for systems above certain thresholds. NFPA 855, §4.1

UL 9540 — system listing

Listing for the complete ESS as a system (cells + BMS + power conversion + thermal management). A unit without a UL 9540 listing cannot be approved for installation under NFPA 855 in most jurisdictions.

UL 9540A — the cell propagation test

The most operationally important test: deliberately driving a cell into thermal runaway to see if it propagates to neighbors. The test report determines the spacing, ventilation, and suppression matrix in NFPA 855 §9. Always ask the integrator for the 9540A report — your AHJ will. Missing this report is the #1 cause of installations being denied a CO.

IFC §1207 (2024) — what your local AHJ enforces

The International Fire Code mirrors NFPA 855. Most U.S. jurisdictions adopt some edition of the IFC. 2024 IFC §1207 aligns closely with NFPA 855 (2023). Reference whichever your state has adopted; a few states adopt NFPA 1 instead.

How thermal runaway actually unfolds

Understanding the timeline matters because it dictates detection, suppression, and emergency-response strategy.

  • Initiation (T = 0). A trigger raises one cell’s internal temperature past about 80°C. Triggers: overcharging, manufacturing defect (rare but headline-grabbing — Galaxy Note 7), mechanical damage (puncture, drop), external heat (vehicle fire, neighboring cell), internal short (dendrite growth from poor cycling).
  • Off-gas phase (T = 0 to several minutes). Cell vents flammable gases — hydrogen (H₂), carbon monoxide, methane, ethylene, electrolyte vapor — through pressure-relief seals. This is the warning window. Properly designed gas detection alarms here, before any flame.
  • Initial flame (T = minutes). The vented gases ignite from cell heat or external arc. Visible jet fire. Cell-to-cell propagation begins as neighboring cell separators melt.
  • Cascade (T = minutes to hours). Each cell that fails dumps heat into its neighbors. In a properly UL 9540A-tested system this stops within the rack; in a poorly designed system it runs through every battery rack in a building.
  • Long-tail re-ignition (T = hours to days). Even after the visible fire is out, individual cells in the damaged pack can re-enter runaway. Tesla EVs are routinely fully submerged for 24-48 hours after a crash to ensure cell stability. BESS containers are often left to burn out under cooling sprays for the same reason.

Detection — what actually works

Thermal runaway is detectable BEFORE the fire if you have the right sensors. Standard smoke detection alone is too late.

  • Off-gas detection. Optical hydrogen sensors or LEL combustible-gas detectors, calibrated for the off-gas signature (H₂ + CO + electrolyte vapors). Industry leaders: Honeywell Battery Safety Sensor, Li-ion Tamer.
  • Heat detection. Linear heat-detection cable rated for the cabinet ambient. Set thresholds tighter than ordinary HVAC use because cells rise fast.
  • VESDA (very early warning). Aspirating smoke detection draws cabinet air across an optical chamber. Detects pre-flame off-gas / particulate at very low concentrations.
  • Cell voltage / temperature monitoring (BMS). The Battery Management System sees voltage anomalies before any external sensor. Modern BMS will isolate a failing module — but only if commissioned correctly. Verify at handover.

Suppression — what works and what doesn’t

You are not putting out a battery fire the way you put out a Class A or B fire. The cathode is releasing its own oxygen at the cell level. Smothering does not stop the chemistry. Your goal is to cool faster than the cells generate heat — which means a very high water flow rate sustained for a very long time.
  • Water (sprinklers + hose streams). Still the gold standard. NFPA 855 generally requires sprinkler coverage at 0.3 gpm/sqft minimum — significantly higher than ordinary occupancy. The flow rate must overcome the heat-generation rate of the failing pack.
  • Clean agent (FK-5-1-12, FM-200, Inergen). Useful for the SECONDARY ignition source (electronics, cabling) but does NOT halt cell-level propagation. Common in indoor BESS as a complement to water, not a replacement. See clean agents.
  • F-500 / encapsulator fluids. Apply as fog from a deck gun. Effective at cooling EV fires (where you can’t flood) and at cell-level penetration in some configurations. Becoming standard in fire department EV / battery response.
  • AVD (vermiculite suspension). Smothers post-fire and isolates damaged cells. Useful for transport / overhaul; not a primary suppression agent.
  • What does NOT work alone: CO₂, dry chemical, foam. Use them on the secondary fuels but do not expect them to stop the battery chemistry.

Inspector checklist (NFPA 855 + IFC §1207)

  • Listing documentation — UL 9540 system listing AND UL 9540A propagation test report on site or with the AHJ. Missing 9540A is the most common finding.
  • Hazard Mitigation Analysis (HMA) for systems above the §4.4.2 threshold. Performed by qualified person. Stamped.
  • Spacing — between cabinets, from exposures, from egress, from openings. Match against NFPA 855 §9 matrix and 9540A results.
  • Detection — gas detection set to alarm on H₂ / CO / electrolyte off-gas, heat detection in cabinet, smoke detection in room. Verify alarm path back to FACP and to the battery management system.
  • Suppression — sprinkler density per design, clean agent (if listed), water mist (if listed). Verify deluge or pre-action interlocks if used.
  • Ventilation — mechanical exhaust at least 1 cfm/sqft, with hydrogen-rated equipment. Verify operable.
  • Egress + signage — direct access to exterior, no battery storage in egress paths, NFPA 704 / hazard placards visible from access roads.
  • Pre-incident plan — copy on file with the fire department. Identifies cell chemistry, energy capacity in kWh, water-supply demand, isolation switches, BMS interface.
  • Emergency shutoff — labeled, accessible from outside the room, integrated with fire-alarm and BMS isolation.
  • Maintenance records — UL 9540A test conditions don’t expire but cell condition does. Verify annual BMS log review and quarterly thermal-camera scan.

What to tell building owners and tenants

  • Buy listed batteries only. UL 2849 for e-bikes, UL 2272 for scooters/hoverboards, UL 9540 for stationary systems, UL 2580 for EV traction batteries. Discount-bin imports skip the listing and they’re the highest source of residential fires.
  • Don’t charge on the egress path. A burning e-bike in a stairwell or hallway turns a survivable apartment fire into a fatal one. NYC’s 2023 e-mobility fire deaths were almost entirely egress-path fires.
  • Don’t modify or repair packs. "Restored" packs, replacement cells from third parties, and DIY repacks of power-tool batteries account for a disproportionate share of incidents.
  • Watch for the warning signs. Bulging case, hot to the touch when not in use, weird smell (sweet / chemical / ester), drop in capacity. Stop using it immediately and store outside.
  • Plan for end-of-life. Don’t throw lithium cells in trash. Most metro areas now have e-waste collection points. A single failed cell in a trash truck has cost cities millions in vehicle fires.

Frequently Asked Questions

Why are lithium-ion battery fires so hard to extinguish?
Unlike a paper or fuel fire, a battery in thermal runaway generates its own heat AND its own oxidizer at the cell level. The cathode releases oxygen during decomposition, so smothering with foam or CO₂ does not stop the chemistry. Cells reignite hours or days after they appear extinguished — the Tesla Megapack fire at Moss Landing (2022) burned for 5 days. Massive water cooling slows propagation but does not "put it out" the way it would on a Class A fire.
What is thermal runaway?
A self-sustaining exothermic reaction inside a lithium-ion cell. A trigger event (overcharge, mechanical damage, internal short, manufacturing defect, external heat) raises cell temperature past ~150°C. The separator melts, anode and cathode short directly, the electrolyte vaporizes and ignites, and the cathode releases oxygen — all within seconds. Heat propagates to neighboring cells and the cycle repeats. A single 18650 cell in runaway puts out ~ 30-50 kJ; a BESS rack can put out tens of GJ.
Does NFPA 855 apply to my e-bike or my home Powerwall?
It depends on capacity. NFPA 855 applies to any ESS over 1 kWh. A Tesla Powerwall (13.5 kWh) is in scope; a single laptop is not. Residential ESS up to 20 kWh has reduced requirements vs commercial / industrial. For e-bikes and e-scooters, the relevant standards are UL 2849 (e-bikes) and UL 2272 (e-scooters / hoverboards). NYC has banned non-listed e-mobility batteries indoors (Local Law 39 / 40 / 41 of 2023) after a wave of fatal apartment fires.
Why does UL 9540A matter?
UL 9540A is the test method that tells you whether one cell going into runaway will propagate to the rest of the battery. The test results determine the spacing, ventilation, and suppression requirements in NFPA 855. A "passing" UL 9540A result (no propagation beyond the initial cell) lets the AHJ approve much tighter installations than a "fail" result. Always ask for the UL 9540A test report — it is what your fire marshal needs.
Can I use F-500 or AVD or other "lithium-specific" agents?
F-500 (encapsulator agent) and AVD (vermiculite-based) have niche roles. F-500 cools cells effectively when applied as fog and is the agent of choice for many fire departments doing offensive interior attack on EV fires. AVD smothers and isolates damaged cells — useful for post-fire overhaul and for transport packaging. Neither is a substitute for the massive water cooling rate (350+ gpm sustained) that actually halts propagation in a BESS.
What does an inspector actually look for at a BESS?
NFPA 855 §4.3-4.4 + IFC §1207: (1) Listing — UL 9540 system label and UL 9540A test report on file; (2) Spacing and setback — 3 ft between battery cabinets, 10 ft from exposures, 5 ft from doors / vents / lot lines per the matrix; (3) Detection — gas-detection (lower flammability limit alarms for off-gas), heat detection, smoke detection; (4) Suppression — sprinklers ≥ 0.3 gpm/sqft over the storage area, OR clean agent OR water mist if listed; (5) Ventilation — mechanical exhaust to limit hydrogen accumulation; (6) Fire department access — pre-incident plan, hazard signage, emergency shutoff. Missing UL 9540A documentation is the single most common finding.

References

1. NFPA 855 (2023): Standard for the Installation of Stationary Energy Storage Systems.

2. UL 9540 (current edition): Energy Storage Systems and Equipment.

3. UL 9540A: Test Method for Evaluating Thermal Runaway Fire Propagation.

4. International Fire Code (2024) §1207: Stationary Storage Battery Systems.

5. EPRI Battery Storage Failure Database (public — search EPRI BESS Failures).

6. NFPA Research Foundation, Lithium-Ion Batteries Hazard and Use Assessment (multiple phases).

7. NYC Local Laws 39, 40, 41 of 2023 — e-mobility battery rules.
